CIRCULAR VIBRATION & SHOCK ISOLATOR

Also known as BOBBIN MOUNTINGS, are simple low cost versatile Isolators of rugged construction for use in wide variety of applications to ease misalignment problems; permit relative movement as in vibratory rollers, shifting & grading machines; as well as a mounting to protect instruments & light equipments and Isolate heavy machines from the harmful effects of Vibration, Shock and Noise.

Typical Applications

Air Conditioning Equipment
Blower
Business Machines
Compressors
Control Panel

Engines
Fans
Generators
Laboratory Instruments
Pumps, etc.

LOAD

Kg To Over 800 Kgs.

DEFLECTION

Upto 15 Mm

Products can be loaded in :

ChatGPT Image 20. juuli 2026, 19_42_18 - Edited.png

MM Bobbins

Male Male Bobbin Mounts are a low cost solution to reducing vibration and shock. They can be used in either Compression or Shear or a combination, and are available with various thread configurations.

Our male male bobbin mounts feature male studs on both sides of the mount for introduction to a female fixing. Normally used when there is access on both sides for a threaded nut. They are used throughout industry and within a wide range of applications, male male bobbin mounts aim to reduce shock and vibrations which could cause damage or instability.

Load Range from 1Kg to 2000Kg per mounting

Stainless Steel option available.
Natural rubber NR
Zinc plated in accordance with CE standards.
Stiffness tolerance: ± 20%

Additional Sizes, Stainless Steel metals and Oil,
Fuel & Heat Resistant rubbers available on request.

Combustion Engines
General Industrial Machinery
Generating Sets
Construction and Agricultural Equipment
Instruments
Transit Cases and Shock Packaging

Products can be loaded in :

Bobbin Mount in use.

SKU	D	H	M+I
7040MM37	70	40	M12×37
7045MM25	70	45	M10×25
7045MM37	70	45	M12×37
7050MM25	70	50	M10×25
7050MM37	70	50	M12×37
7060MM25	70	60	M10×25
7060MM37	70	60	M12×37
7070MM25	70	70	M10×25
7070MM37	70	70	M12×37
7525MM37	75	25	M12×37
7540MM37	75	40	M12×37
7550MM37	75	50	M12×37
7555MM37	75	55	M12×37
8030MM35	80	30	M14×35
8040MM35	80	40	M14×35
8050MM35	80	50	M14×35
8060MM35	80	60	M14×35
8070MM35	80	70	M14×35
8080MM35	80	80	M14×35
10030MM44	100	30	M16×44
10040MM44	100	40	M16×44
10045MM44	100	45	M16×44
10050MM44	100	50	M16×44
10055MM44	100	55	M16×44
10060MM44	100	60	M16×44
10075MM44	100	75	M16×44
100100MM44	100	100	M16×44
15075MM44	150	75	M16×44
4040MM25	40	40	M10×25
4045MM25	40	45	M10×25
5020MM25	50	20	M10×25
5025MM25	50	25	M10×25
5030MM25	50	30	M10×25
5033MM25	50	33	M10×25
5035MM25	50	35	M10×25
5040MM25	50	40	M10×25
5045MM25	50	45	M10×25
5050MM25	50	50	M10×25
6025MM25	60	25	M10×25
6030MM25	60	30	M10×25
6030MM37	60	30	M12×37
6036MM25	60	36	M10×25
6036MM37	60	36	M12×37
6040MM25	60	40	M10×25
6040MM37	60	40	M12×37
6045MM25	60	45	M10×25
6045MM37	60	45	M12×37
6050MM37	60	50	M12×37
6055MM37	60	55	M12×37
6535MM25	65	35	M10×25
6545MM37	65	45	M12×37
6550MM37	65	50	M12×37
7030MM25	70	30	M10×25
7030MM37	70	30	M12×37
7035MM25	70	35	M10×25
7035MM37	70	35	M12×37
7040MM25	70	40	M10×25
0808MM06	8	8	M3×06
1008MM10	10	8	M4×10
1413MM10	14	13	M4×10
1508MM10	15	8	M4×10
1615MM10	16	15	M4×10
1885MM16	18	85	M6×16
2008MM18	20	8	M6×18
2015MM18	20	15	M6×18
2020MM18	20	20	M6×18
2025MM18	20	25	M6×18
2030MM18	20	30	M6×18
2510MM18	25	10	M6×18
2513MM18	25	13	M6×18
2515MM18	25	5	M6×18
2520MM18	25	20	M6×18
2520MM20	25	20	M8×20
2522MM20	25	22	M8×20
2525MM18	25	25	M6×18
2525MM20	25	25	M8×20
2530MM18	25	30	M6×18
2530MM20	25	30	M8×20
2540MM20	25	40	M8×20
3015MM20	30	15	M8×20
3020MM20	30	20	M8×20
3022MM20	30	22	M8×20
3025MM20	30	25	M8×20
3030MM20	30	30	M8×20
3040MM20	30	40	M8×20
4015MM23	40	15	M8×23
4020MM23	40	20	M8×23
4020MM25	40	20	M10×25
4025MM25	40	25	M10×25
4028MM25	40	28	M10×25
4030MM23	40	30	M8×23
4030MM25	40	30	M10×25
4035MM23	40	35	M8×23
4035MM25	40	35	M10×25
4040MM23	40	40	M8×23

Additional info about stiffness, hardness etc available upon request.

MF Bobbins

Male-Female Bobbin Mounts offer a cost-effective solution for minimising vibration and shock. They can be utilised in compression, shear, or a combination of both, and come in a range of thread configurations.

If the fixing thread length is not defined or access is limited at one side of the bobbin, then the Male Female bobbin can be secured via the female thread with a socket screw. We supply Male Female Bobbin Mounts in a selection of sizes with different diameters, thread sizes and heights available.

Load Range from 1Kg to 2000Kg per mounting.

Stainless Steel option available.
Natural rubber NR
Zinc plated in accordance with CE standards.
Stiffness tolerance: ± 20%

Additional Sizes, Stainless Steel metals and Oil,
Fuel & Heat Resistant rubbers available on request.

Combustion Engines
General Industrial Machinery
Generating Sets
Construction and Agricultural Equipment
Instruments
Transit Cases and Shock Packaging

Products can be loaded in :

SKU	D	H	d	M+I
10040MF44	100	40	M16	M16×44
10050MF44	100	50	M16	M16×44
10055MF44	100	55	M16	M16×44
10060MF44	100	60	M16	M16×44
10075MF44	100	75	M16	M16×44
100100MF44	100	100	M16	M16×44
0808MF06	8	8	M3	M3×6
1008MF10	10	8	M4	M4×10
1413MF10	14	13	M4	M4×10
1615MF10	16	15	M4	M4×10
2015MF18	20	15	M6	M6×18
2020MF18	20	20	M6	M6×18
2025MF18	20	25	M6	M6×18
2030MF18	20	30	M6	M6×18
2515MF18	25	15	M6	M6×18
2520MF18	25	20	M6	M6×18
2520MF20	25	20	M8	M8×20
2522MF20	25	22	M8	M8×20
2525MF18	25	25	M6	M6×18
2525MF20	25	25	M8	M8×20
2530MF18	25	30	M6	M6×18
2530MF20	25	30	M8	M8×20
3015MF20	30	15	M8	M8×20
3020MF20	30	20	M8	M8×20
3022MF20	30	22	M8	M8×20
3025MF20	30	25	M8	M8×20
3030MF20	30	30	M8	M8×20
3040MF20	30	40	M8	M8×20
4020MF23	40	20	M8	M8×23
4020MF25	40	20	M10	M10×25
4025MF25	40	25	M10	M10×25
4028MF25	40	28	M10	M10×25
4030MF23	40	30	M8	M8×23
4030MF25	40	30	M10	M10×25
4035MF23	40	35	M8	M8×23
4035MF25	40	35	M10	M10×25
4040MF23	40	40	M8	M8×23
4040MF25	40	40	M10	M10×25
4045MF25	40	45	M10	M10×25
5020MF25	50	20	M10	M10×25
5025MF25	50	25	M10	M10×25
5030MF25	50	30	M10	M10×25
5035MF25	50	35	M10	M10×25
5040MF25	50	40	M10	M10×25
5045MF25	50	45	M10	M10×25
5050MF25	50	50	M10	M10×25
6030MF25	60	30	M10	M10×25
6036MF25	60	36	M10	M10×25
6036MF37	60	36	M12	M12×37
6040MF25	60	40	M10	M10×25
6040MF37	60	40	M12	M12×37
6045MF25	60	45	M10	M10×25
6045MF37	60	45	M12	M12×37
6050MF37	60	50	M12	M12×37
6055MF37	60	55	M12	M12×37
6535MF25	65	35	M10	M10×25
6545MF37	65	45	M12	M12×37
6550MF37	65	50	M12	M12×37
7030MF25	70	30	M10	M10×25
7030MF37	70	30	M12	M12×37
7035MF25	70	35	M10	M10×25
7035MF37	70	35	M12	M12×37
7040MF25	70	40	M10	M10×25
7040MF37	70	40	M12	M12×37
7045MF25	70	45	M10	M10×25
7045MF37	70	45	M12	M12×37
7050MF25	70	50	M10	M10×25
7050MF37	70	50	M12	M12×37
7060MF25	70	60	M10	M10×25
7060MF37	70	60	M12	M12×37
7070MF25	70	70	M10	M10×25
7070MF37	70	70	M12	M12×37
7540MF37	75	40	M12	M12×37
7550MF37	75	50	M12	M12×37
7555MF37	75	55	M12	M12×37
8030MF35	80	30	M14	M14×35
8040MF35	80	40	M14	M14×35
8050MF35	80	50	M14	M14×35
8050MF37	80	50	M12	M12×37
8060MF35	80	60	M14	M14×35
8070MF35	80	70	M14	M14×35
8080MF35	80	80	M14	M14×35

Additional info about stiffness, hardness etc available upon request.

FF Bobbins

Female-Female Bobbin Mounts provide an affordable solution for reducing vibration and shock. Suitable for use in compression, shear, or a combination of both, they are available with a variety of thread configurations.

Our Female Female Bobbin Mounts feature double sided female thread designed for installation onto Male studs and fixings. As with others in the range, we are able to offer Female Female Bobbin Mounts in different sizes and materials. Get in touch if you need a customised solution.

Load Range from 1Kg to 2000Kg per mounting.

Stainless Steel option available.
Natural rubber NR
Zinc plated in accordance with CE standards.
Stiffness tolerance: ± 20%

Additional Sizes, Stainless Steel metals and Oil,
Fuel & Heat Resistant rubbers available on request.

Small Machines
Instruments
Radiators
Combustion Engines
Pumps

Products can be loaded in :

SKU	D	H	M
1413FF04	14	13	M4
1615FF04	16	15	M4
1615FF05	16	15	M5
2015FF06	20	15	M6
2020FF06	20	20	M6
2025FF06	20	25	M6
2030FF06	20	30	M6
2515FF06	25	15	M6
2520FF06	25	20	M6
2522FF08	25	22	M8
2525FF06	25	25	M6
2530FF06	25	30	M6
2530FF08	25	30	M8
3020FF08	30	20	M8
3025FF08	30	25	M8
3030FF08	30	30	M8
3040FF08	30	40	M8
4020FF08	40	20	M8
4028FF08	40	28	M8
4028FF10	40	28	M10
4030FF08	40	30	M8
4030FF10	40	30	M10
4035FF08	40	35	M8
4035FF10	40	35	M10
4040FF08	40	40	M8
4040FF10	40	40	M10
4045FF10	40	45	M10
5025FF10	50	25	M10
5030FF10	50	30	M10
5035FF10	50	35	M10
5040FF10	50	40	M10
5045FF10	50	45	M10
5050FF10	50	50	M10
6036FF10	60	36	M10
6036FF12	60	36	M12
6040FF10	60	40	M10
6040FF12	60	40	M12
6045FF10	60	45	M10
6045FF12	60	45	M12
6050FF12	60	50	M12
6055FF12	60	55	M12
6535FF10	65	35	M10
6545FF10	65	45	M10
6545FF12	65	45	M12
6550FF12	65	50	M12
7030FF10	70	30	M10
7030FF12	70	30	M12
7035FF10	70	35	M10
7035FF12	70	35	M12
7040FF10	70	40	M10
7040FF12	70	40	M12
7045FF10	70	45	M10
7045FF12	70	45	M12
7050FF10	70	50	M10
7050FF12	70	50	M12
7060FF10	70	60	M10
7060FF12	70	60	M12
7070FF10	70	70	M10
7070FF12	70	70	M12
7540FF12	75	40	M12
7550FF12	75	50	M12
7555FF12	75	55	M12
8040FF14	80	40	M14
8050FF12	80	50	M12
8050FF14	80	50	M14
8060FF14	80	60	M14
8070FF14	80	70	M14
8080FF14	80	80	M14
10040FF16	100	40	M16
10045FF16	100	45	M16
10050FF16	100	50	M16
10055FF16	100	55	M16
10060FF16	100	60	M16
100100FF16	100	100	M16
15075FF16	150	75	M16
15075FF20	150	75	M20

Additional info about stiffness, hardness etc available upon request.

WMM Bobbins

Waisted Bobbin Mounts are ideal for applications where the predominant force or vibration is in the lateral direction. By design, the waisted bobbins provide a low shear stiffness which provides more deflection and an increased level of vibration reduction in the lateral direction.

The Wasted Bobbin Mounts range is available in various sizes and thread configurations. Stainless Steel metals and Oil Resistant / High Temperature rubbers are available on request.

Stainless Steel option available.
Natural rubber NR
Zinc plated in accordance with CE standards.
Stiffness tolerance: ± 20%

SKU	D	H	d	M+I
1015WMM410	10	15	6	M4×10
1214WMM410	12	14	7	M4×10
1214WMM510	12	14	7	M5×10
1615WMM510	16	15	125	M5×10
2019WMM18	20	19	145	M6×18
2520WMM18	25	20	10	M6×18
2520WMM18	25	20	17	M6×18
3020WMM20	30	20	24	M8×20
4030WMM23	40	30	15	M8×23
4030WMM23	40	30	27	M8×23
6060WMM25	60	60	50	M10×25

Additional info about stiffness, hardness etc available upon request.

Lightweight Equipment
Vibratory Feeders
Electric Motors
Control Panels
Measuring Apparatus

Products can be loaded in :

WMF Bobbins

The Wasted Bobbin Mounts range is available in various sizes and thread configurations. Stainless Steel metals and Oil Resistant / High Temperature rubbers are available on request.

Stainless Steel option available.
Natural rubber NR
Zinc plated in accordance with CE standards.
Stiffness tolerance: ± 20%

SKU	D	H	G	d	M+I
1015WMF10	10	15	6	M4	M4×10
2019WMF18	20	19	14.5	M6	M6×18
2520WMF18	25	20	10	M6	M6×18
2520WMF18	25	20	17	M6	M6×18
3020WMF20	30	20	24	M8	M8×20
4030WMF23	40	30	15	M8	M8×23
4030WMF23	40	30	27	M8	M8×23
6060WMF25	60	60	50	M10	M10×25

Additional info about stiffness, hardness etc available upon request.

Lightweight Equipment
Vibratory Feeders
Electric Motors
Control Panels
Measuring Apparatus

Products can be loaded in :

WFF Bobbins

The Wasted Bobbin Mounts range is available in various sizes and thread configurations. Stainless Steel metals and Oil Resistant / High Temperature rubbers are available on request.

Stainless Steel option available.
Natural rubber NR
Zinc plated in accordance with CE standards.
Stiffness tolerance: ± 20%

Lightweight Equipment
Vibratory Feeders
Electric Motors
Control Panels
Measuring Apparatus

Products can be loaded in :

SKU	D	H	G	d
1015WFF03	10	15	6	M3
1015WFF04	10	15	6	M4
2019WFF06	20	19	14.5	M6
2520WFF06	25	20	17	M6
3020WFF08	30	20	24	M8
4030WFF08	40	30	15	M8
4030WFF08	40	30	27	M8
6060WFF10	60	60	50	M10

Additional info about stiffness, hardness etc available upon request.

HMC Bobbins

Hexagon Bobbin Mounts are manufactured with hexagonal end metals to allow the fitter to grip the mounting with a spanner to avoid twisting of the rubber during installation.

Mountings can be used in Compression, Shear or a combination of both and can accommodate compression loads from 4kg to 110kg per mounting.

Stainless Steel option available.
Natural rubber NR
Zinc plated in accordance with CE standards.
Stiffness tolerance: ± 20%

SKU	D	H	d	L	Compression load kg	Compression load mm	Shear load kg	Shear load mm
HMC1382/45	16	16	M6	12	4.0	1.0	3	3.8
HMC1382/60	16	16	M6	12	8.0	1.0	3.2	1.8
HMC1383/45	21	19	M8	20	8.0	1.2	7.0	6.5
HMC1383/60	21	19	M8	20	16.0	1.2	6.5	2.7
HMC1384/45	32	26	M8	16	16.0	2.0	10.0	7.0
HMC1384/60	32	26	M8	16	31.0	2.0	11.0	3.5
HMC1385/45	33	22	M10	25	29.0	1.5	13.0	4.5
HMC1385/60	33	22	M10	25	57.0	1.5	14.0	2.5
HMC1386/45	43	25	M12	30	58.0	1.7	28.0	6.0
HMC1386/60	43	25	M12	30	110.0	1.7	30.0	3.0
HMC200/60	32	23	M8	18	36.0	1.5	13.0	3.5

Control Panels
Industrial Equipment
Radiators
Exhaust Systems and General purpose machinery

Products can be loaded in :

Additional info about stiffness, hardness etc available upon request.
