Flanged Mounts

MC Flanged Mounts

The MC, FC range of mounts are extremely versatile. These are used in various applications that require only overcoming compression forces. These mounts can be supplied either with a male screw (MC) or with a threaded insert (FC). These come with a flange at the bottom to simplify installation. These range of mounts can accommodate loads ranging from 20kg until 4000kg per mount.

Pumps
Measurement Equip.
HVAC
Radiators
Small Machinery

Products can be loaded in :

SKU	A	B	L	P	F x M (F1 x M1)	CF1	CF2	L1	L2	S	Type
7050MC38SS	71	50	37	M12	12	100	-	127	77	3	A
7050MC38M	71	50	37	M12	12	100	-	127	77	3	A
7050MC38H	71	50	37	M12	12	100	-	127	77	3	A
7050MCS38SS	71	50	37	M12	12	100	-	127	76	3	B
7050MCS38M	71	50	37	M12	12	100	-	127	76	3	B
7050MCS38H	71	50	37	M12	12	100	-	127	76	3	B
8550MC38SS	88	48	37	M12	11	112	-	144	94	3	A
8550MC38M	88	48	37	M12	11	112	-	144	94	3	A
8550MC38H	88	48	37	M12	11	112	-	144	94	3	A
10580MC38SS	100	80	38	M20	14 (14x17.2)	138	144.5	174	108	4	C
10580MC38M	100	80	38	M20	14 (14x17.2)	138	144.5	174	108	4	C
10580MC38H	100	80	38	M20	14 (14x17.2)	138	144.5	174	108	4	C
12564MC42SS	124	64	42	M20	18x23 (18x23)	177	182	215	144	4	A
12564MC42M	124	64	42	M20	18x23 (18x23)	177	182	215	144	4	A
12564MC42H	124	64	42	M20	18x23 (18x23)	177	182	215	144	4	A
15280MC38SS	152	80	38	M20	18 (18x21.7)	190	197.5	232	168	4	C
15280MC38M	152	80	38	M20	18 (18x21.7)	190	197.5	232	168	4	C
15280MC38H	152	80	38	M20	18 (18x21.7)	190	197.5	232	168	4	C

Additional info about stiffness, hardness etc available upon request.

FC Flanged Mounts

The MC, FC range of mounts are extremely versatile. These are used in various applications that require only overcoming compression forces. These mounts can be supplied either with a male screw (MC) or with a threaded insert (FC). These come with a flange at the bottom to simplify installation. These range of mounts can accommodate loads ranging from 20kg until 4000kg per mount.

Pumps
Measurement Equip.
HVAC
Radiators
Small Machinery

Products can be loaded in :

SKU	A	B	P	F x M (F1 x M1)	CF1	CF2	L1	L2	S	Type
7050FC12SS	70	50	M12	12	100	-	127	77	3	A
7050FC12M	70	50	M12	12	100	-	127	77	3	A
7050FC12H	70	50	M12	12	100	-	127	77	3	A
7050FCS12SS	70	50	M12	12	100	-	127	76	3	B
7050FCS12M	70	50	M12	12	100	-	127	76	3	B
7050FCS12H	70	50	M12	12	100	-	127	76	3	B
8550FC12SS	85	48	M12	11	112	-	144	94	3	A
8550FC12M	85	48	M12	11	112	-	144	94	3	A
8550FC12H	85	48	M12	11	112	-	144	94	3	A
10580FC20SS	105	80	M20	14 (14x17,25)	138	144.5	174	108	4	C
10580FC20M	105	80	M20	14 (14x17,25)	138	144.5	174	108	4	C
10580FC20H	105	80	M20	14 (14x17,25)	138	144.5	174	108	4	C
12564FC20SS	125	64	M20	18x23 (18x23)	177	182	215	144	4	A
12564FC20M	125	64	M20	18x23 (18x23)	177	182	215	144	4	A
12564FC20H	125	64	M20	18x23 (18x23)	177	182	215	144	4	A
15280FC20SS	152	80	M20	18 (18x21,75)	190	197.5	232	168	4	C
15280FC20M	152	80	M20	18 (18x21,75)	190	197.5	232	168	4	C
15280FC20H	152	80	M20	18 (18x21,75)	190	197.5	232	168	4	C

Additional info about stiffness, hardness etc available upon request.

FFC Flanged Mounts

The FFC range of mounts are extremely versatile. Rectangular flanged rubber mounts were designed for providing low shear stiffness rates with large compression forces. These are used in various applications that require only overcoming compression forces.

Generating Sets
Pumps
Compressors
Processing Equipment

Products can be loaded in :

SKU	A	B	C	D	F	CF	L1	L2	P	S
FFC763812	76	39	14	25	28	99-128	165	83	M12	3

Additional info about stiffness, hardness etc available upon request.

MCI Flanged Mounts

The MCI, FCI range of mounts are a higher spec to the MC, FC range. These mounts are designed with a metal insert within the elastomeric part. This allows the mounts to support higher loads than the MC, FC range, and also enables it to absorb huge impulsive charges under full power, whilst maintaining the necessary levels of deflection and insulation for effective operation. This range of Mounts can accommodate loads between 45kg to 3,200kg per Mount.

Pumps
Measurement Equip.
HVAC
Radiators
Small Machinery

Products can be loaded in :

Height adjusters

Optional modifications / extras:

SKU	A	B	L	P	F x M (F1 x M1)	CF1	CF2	L1	L2	S	Type
7050MCI38SS	70	50	37	M12	12	100	-	127	77	3	A
7050MCI38M	70	50	37	M12	12	100	-	127	77	3	A
7050MCI38H	70	50	37	M12	12	100	-	127	77	3	A
7050MCIS38SS	70	50	37	M12	12	100	-	127	76	3	B
7050MCIS38M	70	50	37	M12	12	100	-	127	76	3	B
7050MCIS38H	70	50	37	M12	12	100	-	127	76	3	B
8550MCI38SS	85	50	37	M12	11	112	-	144	94	3	A
8550MCI38M	85	50	37	M12	11	112	-	144	94	3	A
8550MCI38H	85	50	37	M12	11	112	-	144	94	3	A
10580MCI38SS	105	80	38	M20	(14x17,25)	138	144.5	174	108	4	C
10580MCI38M	105	80	38	M20	(14x17,25)	138	144.5	174	108	4	C
10580MCI38H	105	80	38	M20	(14x17,25)	138	144.5	174	108	4	C
12564MCI42SS	125	64	42	M20	18x23 (18x23)	177	182	215	144	4	A
12564MCI42M	125	64	42	M20	18x23 (18x23)	177	182	215	144	4	A
12564MCI42H	125	64	42	M20	18x23 (18x23)	177	182	215	144	4	A

Additional info about stiffness, hardness etc available upon request.

FCI Flanged Mounts

The MCI, FCI range of mounts are a higher spec to the MC, FC range. These mounts are designed with a metal insert within the elastomeric part. This allows the mounts to support higher loads than the MC, FC range, and also enables it to absorb huge impulsive charges under full power, whilst maintaining the necessary levels of deflection and insulation for effective operation. This range of Mounts can accommodate loads between 45kg to 3,200kg per Mount.

Pumps
Measurement Equip.
HVAC
Radiators
Small Machinery

Isolators can be loaded in :

Height adjusters

Optional modifications / extras:

SKU	A	B	P	F x M (F1 x M1)	CF1	CF2	L1	L2	S	Type
7050FCI12SS	71	50	M12	12	100	-	127	77	3	A
7050FCI12M	71	50	M12	12	100	-	127	77	3	A
7050FCI12H	71	50	M12	12	100	-	127	77	3	A
7050FCIRS12SS	71	50	M12	12	100	-	127	76	3	B
7050FCIRS12M	71	50	M12	12	100	-	127	76	3	B
7050FCIRS12H	71	50	M12	12	100	-	127	76	3	B
8550FCI12SS	88	48	M12	11	112	-	144	94	3	A
8550FCI12M	88	48	M12	11	112	-	144	94	3	A
8550FCI12H	88	48	M12	11	112	-	144	94	3	A
10580FCI20SS	100	80	M20	(14x17,25)	138	144.5	174	108	4	C
10580FCI20M	100	80	M20	(14x17,25)	138	144.5	174	108	4	C
10580FCI20H	100	80	M20	(14x17,25)	138	144.5	174	108	4	C
12564FCI20SS	124	64	M20	18x23 (18x23)	177	182	215	144	4	A
12564FCI20M	124	64	M20	18x23 (18x23)	177	182	215	144	4	A
12564FCI20H	124	64	M20	18x23 (18x23)	177	182	215	144	4	A

Additional info about stiffness, hardness etc available upon request.

DHM Flanged Mounts

The DH range of mounts are a versatile range of mounts that can be used in a variety of applications. The door shaped hollow within the rubber section enables the mount to provide high levels of vibration isolation and shock absorption. These mounts can accommodate loads ranging from 20kg until 470kg.

Pumps
Measurement Equip.
HVAC
Radiators
Small Machinery

Isolators can be loaded in :

Height adjusters

Optional modifications / extras:

SKU	A1	A2	V	H1	H2	F	L1	L2	L3
11550DHM37M	40	60	M12	45	37	13.2	115	85	50
16510DHM37M	40	60	M12	45	37	13.2	165	135	100
215150DHM37M	40	60	M12	45	37	13.2	215	185	150

Additional info about stiffness, hardness etc available upon request.

DHF Flanged Mounts

The DH range of mounts are a versatile range of mounts that can be used in a variety of applications. The door shaped hollow within the rubber section enables the mount to provide high levels of vibration isolation and shock absorption. These mounts can accommodate loads ranging from 20kg until 470kg.

Pumps
Measurement Equip.
HVAC
Radiators
Small Machinery

Isolators can be loaded in :

Height adjusters

Optional modifications / extras:

SKU	A1	A2	D	H1	F	L1	L2	L3
11550DHF12M	40	60	M12	45	13.2	115	85	50
16510DHF12M	40	60	M12	45	13.2	165	135	100
215150DHF12M	40	60	M12	45	13.2	215	185	150

Additional info about stiffness, hardness etc available upon request.

DHMM Flanged Mounts

The FFC range of mounts are extremely versatile. Rectangular flanged rubber mounts were designed for providing low shear stiffness rates with large compression forces. These are used in various applications that require only overcoming compression forces.

Generating Sets
Pumps
Compressors
Processing Equipment

Products can be loaded in :

SKU	F	D	B	H	M	I	S
DHMM60	105	80	70	55	M12	35	130

Additional info about stiffness, hardness etc available upon request.

FT Turret Mounts

Turret mountings are engineered to provide reliable vibration isolation for HVAC and other static equipment applications. The rubber element is fully bonded to encapsulate the metal inserts, preventing corrosion and enhancing durability in demanding environments.

With their high deflection capability, these mountings effectively minimize vibration transmission and noise, ensuring smooth equipment operation even at lower running speeds.

HVAC
Fans
Pumps
Compressors

Products can be loaded in :

SKU	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	F (mm)	G (mm)	H (mm)	I (mm)
TM229	62	49.2	38	4.8	4.8	29.5	5.5	35.3	M8
TMS	80	54-60	45	9	12	32	5	41	M8
TMM	95	67-76	60	9	14	45	5	56	M10
TML	150	105-126	86	11	22.5	70	6	82	M12

Additional info about stiffness, hardness etc available upon request.

FFT Turret Mounts

Turret mountings are engineered to provide reliable vibration isolation for HVAC and other static equipment applications. The rubber element is fully bonded to encapsulate the metal inserts, preventing corrosion and enhancing durability in demanding environments.

With their high deflection capability, these mountings effectively minimize vibration transmission and noise, ensuring smooth equipment operation even at lower running speeds.

Not encapsulated

HVAC
Fans
Pumps
Compressors

Products can be loaded in :

SKU	A (mm)	B (mm)	C (mm)	D (mm)	E (mm)	F (mm)	G (mm)	H (mm)	I (mm)
FFT6535	65	48	-	7.5	-	36	2	51	M10

Additional info about stiffness, hardness etc available upon request.

CM Flanged Mounts

Flanged Mountings are designed to provide high levels of deflection, ensuring superior vibration isolation and effective shock absorption in both vertical and horizontal directions. Their robust design makes them particularly suitable for isolating low-speed machinery and equipment, helping to reduce vibration transmission, improve operational stability, and extend equipment service life.

Pumps
Fans
Compressors
Vibratory Screens
Shock Packaging

Isolators can be loaded in :

SKU	A (mm)	B (mm)	C	D (mm)	E (mm)	F (mm)	G (mm)
CM1566	26.5	11.6	M6	50	60	1.74	6
CM209	31	21.5	M8/M10	60	77	3	9.2
CM007	18	20	M6	50	64	2	7
CM25	33	25	M8/M10	66-73	85	2	8x12
CM50	45	35	M10	92	114	2	10
CM100	53	40	M10	110	136	2	11.5
CM200	58	45	M10	124	151	3	11.5

Additional info about stiffness, hardness etc available upon request.

SCM Flanged Mounts

Flanged Mountings are designed to provide high levels of deflection, ensuring superior vibration isolation and effective shock absorption in both vertical and horizontal directions. Their robust design makes them particularly suitable for isolating low-speed machinery and equipment, helping to reduce vibration transmission, improve operational stability, and extend equipment service life.

Pumps
Fans
Compressors
Vibratory Screens
Shock Packaging

Products can be loaded in :

SKU	A (mm)	B (mm)	C	D (mm)	E (mm)	F (mm)	G (mm)
SCM400	70	63	M12	120	150	3	14.5
SCM600	100	85	M16	160	200	4	14.5
SCM1500	186	160	M24	250	310	6	18

Additional info about stiffness, hardness etc available upon request.

CFM Flanged Mounts

Flanged Mountings are designed to provide high levels of deflection, ensuring superior vibration isolation and effective shock absorption in both vertical and horizontal directions. Their robust design makes them particularly suitable for isolating low-speed machinery and equipment, helping to reduce vibration transmission, improve operational stability, and extend equipment service life.

Pumps
Fans
Compressors
Vibratory Screens
Shock Packaging

Products can be loaded in :

SKU	A	B	C	D	E	F	G	H
CFM4020	40	20	M6	19	29	52	64	6.2
CFM6024	60	24	M6	14	34	76	90	6.2
CFM8027	80	27	M8	25	65	100	120	8.2
CFM10028	100	28	M10	22	70	124	148	10.0
CFM15039	150	39	M14	34	115	182	214	12.0
CFM20044	200	44	M18	35	140	240	280	15

Additional info about stiffness, hardness etc available upon request.

HDF Flanged Mounts

Flanged Mountings are designed to provide high levels of deflection, ensuring superior vibration isolation and effective shock absorption in both vertical and horizontal directions. Their robust design makes them particularly suitable for isolating low-speed machinery and equipment, helping to reduce vibration transmission, improve operational stability, and extend equipment service life.

Pumps
Fans
Compressors
Vibratory Screens
Shock Packaging

Products can be loaded in :

SKU	A	B	C	D	D1	E1	E2	F	G
HDF4012	12	40	M6	52	40	64	44	2.5	6.2x6.2
HDF6050	32	40	M6	76	60	90	64	2.5	8.2x6.2
HDF80130	48	40	M8	100	80	122	84	2.5	12.2x8.2
HDF100260	68	40	M10	124	100	152	104	3	16.2x10.2
HDF150500	116	40	M12	182	150	214	154	4.5	20.2x12.2
HDF2001350	159	40	M16	240	200	280	204	5.5	24.2x14.2

Additional info about stiffness, hardness etc available upon request.
